  • Automatic
  • New Britain
  • Model 62 2-1/4"
  • Multi Spindle Bar
  • 6 Spindle
  • 1975
New Britain Model 62 2-1/4

Specifications

STANDARD SPECIFICATIONS
Height: 6'5"
Length:12'
Weight:19,000 lbs
Width:4'8"
Cap. Round: 1 5/8" or 2 1/4"
Coolant Capacity 130 Gallons
Idle 1.52 w/3" Tool Slide Cam
Idle 1.66 w/6" Tool Slide Cam
Max Die Head Dia: 5 1/4"
Max Feed Lower Slides 1.655"
Max Stock Feed 7 1/2"
Max Feed Mid Slides 1.504"
Max Feed Top Slides 1.504"
Max Trav Lower Slides 2 9/16"
Max Trav Mid Slides 2 5/16"
Max Trav Top Slides 2 5/16"
Motor Horsepower 15-30 at 1800 RPM
Spindle Speeds 177-2519
Standard Bearings: Ball
Tool Slide Travel 6"

Notes

62 New Britain 6-Spindle Machine. Bar Capacity 2-1/4 ,
Serial Number #38653, Purchased in 1975.
Electric Threading Attachment
Threading in 4Th and 5Th positions
Set up for Winters Thread Rolls
Thread Cams for Winter and Fette Thread Rolls
Cams fr 1/16 t 3/4
Includes Tool Holders in All 6 Positions
Rpm 2800 - Ball Bearing machine.
Machine Manual
Mist Collect
Electric Chip Conveyr
NB 62 ser no 38653. 3/60/460 volt. Flat conveyor, Aercology mist, bar
feed w enclousre, 6 slides, 3 form tools, 2 sets of spindle liners, 6
tool holders. Spindle bearings sound good. tool slide lift .002,
is making good ISO parts for a spray nozzle manufacturer.
