Sold!Buy one like this
I want to sell a machine like this
- Automatic
- New Britain
- Model 52
- Multi Spindle Bar
- 6 Spindle
- 1964
Specifications
Maximum Capacity - Round 1-1/4"- Hexagon 1-1/16"
- Square 7/8"
Stock Feed - Maximum 5"
Tool Slide Travel 4"
Travel (Lower Slides) Front - Maximum 1-3/4"
Travel (Lower Slides) Rear - Maximum 2"
Lower Slides Feed - Maximum 1"
Middle Slides Travel - Maximum 1-3/4"
Middle Slides Feed - Maximum 1"
Travel (Upper Slides) Front - Maximum 1-3/4"
Travel (Upper Slides) Rear - Maximum 2"
Upper Slides Feed - Maximum 1"
Spindle Speeds 271 - 4249 RPM
Approximate Weight 12,900 Lbs.
Notes
Chip Conveyor - Drag
Auxiliary Pos 4
Drill Speeder
2 Circle Form Holders
440/3/60
Stock Reel and Stand
Cams and Gears
Master Collets
Pusher Tubes
Covers and Guards
Main Tool Slide Hangers
Speed and Feed Gears
Mechanical Feed Clutches
Oil Mist Collector
