  • CNC Machine
  • Gildemeister
  • MF Twin 65 Mill-Turn
  • Lathe - CNC
  • 65mm
  • 2000
  • Y Axis:
  • Dual Spindles:
  • Live Tooling:
  • Dual Turrets:
 Gildemeister MF Twin 65 Mill-Turn Lathe - CNC 65mm 2000

Specifications

General Specifications As Per Brochure
Located in South America - 60 Cycle Electrics
Working Area:
Clamp Diameter: 7.9"
Bar Diameter: 2.6"
Max. Distance Between Spindles: 31.5"
Slide Travel (X1, X2), Transverse: 7.5"/7.5"
Slide Travel (Z1, Z2) Longitudinal 21.8"/21.8"
Longitudinal Travel, Spindle 2: 23.6"
Workspindle 1:
Spindle Nose (Flat Nose): 170h5mm
Spindle Bore: 3.1"
Spindle Diameter In Front Bearing: 4.7"
Workspindle 2:
Spindle Nose (Flat Nose): 140h5mm
Spindle Bore: 2.2"
Spindle Diameter In Front Bearing: 3.5"
Main Drive 1 (Integral Spindle Motor):
Drive Output, Continuous Duty: 28.1 Horsepower
Speed Range: 25 - 5,000 Rpm
Main Drive 2 (Integral Spindle Motor):
Drive Output, Continuous Duty: 16.1 Horsepower
Speed Range: 31 - 6,300 Rpm
Turrets 1 And 2:
Number Of Tool Stations: 2x12
Driven Tool Stations: 2x12
Drive Output (40% Duty Cycle): 8.8 Horsepower
Torque (40% Duty Cycle): 14.8 Ft./Lb.
Equipped With (Must Be Verified By Buyer):

Notes

Gildemesiter Twin 65
Y axis on upper turret
Serial Number
Year of manufacture 2000
Twin turret - 12 live tool positions each one
Type of toolholders VDI 30
Twin spindle 63mm main spindle
Number of live holders 30
Other holders 27
