Specifications

Chuck Size 8"
Max Diameter Bar Capacity 2.5"
Max Swing Over Bed / Carriage / Front Cover 26.8" / 20.1" / 18"
Turning Diameter (Max / Std) 15.3" / 8.2"
Distance Between Spindles 29.6"
Max Machining Length 12.7"
Spindle Motor 15 / 10 HP
Spindle Speed 45 - 4500 RPM
Spindle Bore 2.9"
Spindle Nose A2-6
Spindle Torque 180 ft. lbs.
Tools 12 (All Live)
Milling Motor 7.9 / 6.0 HP
Milling Speed 3000 RPM
Sub Spindle Motor 10 / 7.5 HP
Sub Spindle Speed 60 - 6000 RPM
Rapid Traverse Rates (X / Z) 708 / 945 IPM
X-Axis Travel 9.3"
Z-Axis Travel 19.5"
C-Axis Index .001 Degrees
Turret Index (Single Step) 0.2 Seconds
Machine Dimensions (L x W x H) 169.9" x 73.3" x 103.3"
Machine Weight 9900 lbs.
GANTRY SPECIFICATIONS:
Max Workpiece Diameter 0.79" - 5.9"
Max Workpiece Length 0.39" - 3.94"
Max Workpiece Weight 11 lbs. x 2
Max Stack Height 18.5"
